LXSG 25 MULTI JET

Super Dry Type Cast Iron Flow Water Meter

Features

Multi-jet, Dry-dial, easy to maintenance;
Magnetic drive reliable characteristic, long working life;
Register is sealed in the capsule with special liquid keep a clear presentation in along term servise;
Selected high quality materials for steady & reliable characteristic
Technical data conform to international standard ISO4064 Class B

Working condition:
Water temperature: 0.1°C~40ºC for cold water meter.
Water Pressure: ≤ 1.0Mpa or 1.6Mpa

Maximum permissible error:
in the lower zone from qmin inclusive up to but excluding q t is ± 5%;
in the upper zone form q t inclusive up to and including q s is ± 2%.
Hot water meter ±3%

MAIN TECHNICAL  SPECIFICATIONS
    Type Size

(mm)

 Class qs qp qt qmin Minimum Maximum
Overload

Flow

 Permanent

Flow

 Transitional

 Flow

 Minimum

Flow

 Reading Reading
m3/h L/h m3
 LXSG-15 15 B 3 1.5 120 30 0.00005 99,999
 LXSG-20 20 B 5 2.5 200 50 0.00005 99,999
 LXSG-25 25 B 7 3.5 280 70 0.00005 99,999
 LXSG-32 32 B 12 6 480 120 0.00005 99,999
 LXSG-40 40 B 20 10 800 200 0.00005 99,999
LXSG-50 50 B 30 15 3000  450 0.00005 99,999
