Features

–Removable element structure, easy installation and maintenance, register for universal use within this range detachable without Removing the meter fromthe pipeline;
–Dry-dial,Magnetic drive sensitive action, small pressure loss;
–Vacuum sealed register ensures the dial keep free fromfog and Keep the reading clear in a long term service;
–Selected high quality materials for steady & reliable characteristic;
–Technical data conformto international standard ISO 4064 Class  B.

Type Size(mm) Class Qs Overload Flow Qp Permanent Flow Qt Transitinal Flow Qmin

Min.

Flow

Min. Reading Max.

Reading

m³/h
LXLC-40 40 B 20 10 2 0.300 0.01 999,999
LXLC-50 50 B 30 15 3 0.45 0.01 999,999
LXLC-65 65 B 50 25 5 0.75 0.01 999,999
LXLC-80 80 B 80 40 8 1.20 0.01 999,999
LXLC-100 100 B 130 60 12 1.80 0.01 999,999
LXLC-125 125 B 200 100 20 3.00 0.01 999,999
LXLC-150 150 B 300 150 30 4.50 0.01 999,999
LXLC-200 200 B 500 250 50 7.50 0.01 999,999
LXLC-250 250 B 800 400 80 12.00 0.01 999,999
LXLC-300 300 B 1200 600 120 18.00 0.01 999,999
LXLC-400 400 B 2000 100 200 30.00 0.01 999,999
LXLC-500 500 B 3000 1500 300 45.00 0.01 999,999
